Mobile Amplifier Plan Set • Minimum Order: $25.00 in Parts • Product Returns are subject to 15% Re-stock fee.

Amplifier Plans

Assembly plans reminiscent of the old “Heathkit” manuals. Describes step-by-step technical and construction details for assembling modern 3.5-29.7 MHz solid state amplifiers. Includes listing of easily obtainable parts and their suppliers. Ideal booster for low power transceivers including the popular HR-2510, HR-2600, HTX-100, RCI-2950, AR-3500. External L.P. filters may be required for 80-15 Meter bands. Power: 125w-200w CW/AM/FM, 75-300w PEP depending on transistors selected. Part Number: CAOML     •      $15.00 ea. Note: The Printed Circuit Board for this kit has been discontinued.
